The main features:
The classic decorative pattern is mainly for general road conditions.
Also be suitable for complex road conditions
Unique tread belt structure tread design using stratified
High wear-resistance. Low heat generation&a
| SIZE | PR | LOAD INDEX | SPEED SYMBOL | PATTERN DEPTH (mm) | STANDARD RIM | PERMITTED RIM | MAX LOAD (Kg) | PRESSURE (Kpa) | NEW TIRE INFLATED DIMENSION (mm) | ||
| S | D | OD | SW | ||||||||
| ±1.0% | ±3.5% | ||||||||||
| 7.00R16 | 14 | 118/114 | K | 12.00 | 5.50F | 6.00G | 1320 | 1180 | 770 | 775 | 205 |
| 7.50R16 | 14 | 122/118 | K | 12.50 | 6.00G | 5.50F, 6.50H | 1500 | 1320 | 770 | 805 | 215 |
| 8.25R16 | 16 | 128/124 | K | 13.00 | 6.50H | 6.00G, 6.5 | 1800 | 1600 | 770 | 855 | 235 |
| 8.25R20 | 16 | 139/137 | K | 14.00 | 6.50 | 6.00 | 2430 | 2300 | 900 | 974 | 236 |
| 9.00R20 | 16 | 144/142 | K | 15.50 | 7 | 7.00T,7.5 | 2800 | 2650 | 900 | 1018 | 259 |
| 10.00R20 | 18 | 149/146 | K | 17.00 | 7.5 | 7.50V,8.0 | 3250 | 3000 | 930 | 1054 | 278 |
| 11.00R20 | 18 | 152/149 | K | 17.00 | 8 | 8.00V,8.5 | 3550 | 3250 | 930 | 1085 | 293 |
| 12.00R20 | 18 | 154/151 | K | 17.50 | 8.5 | 8.50V,9.0 | 3750 | 3450 | 830 | 1125 | 315 |
| 12.00R24 | 20 | 160/157 | K | 16.00 | 8.5 | 8.50V,9.0 | 4500 | 4125 | 900 | 1226 | 315 |
| 315/80R22.5 | 18 | 154/151 | M | 17.00 | 9 | 9.75 | 4000 | 3650 | 850 | 1076 | 312 |
| 13R22.5 | 18 | 154/151 | L | 15.50 | 9.75 | 9 | 3750 | 3450 | 830 | 1124 | 320 |
