The main features:
Designed for all wheels of truck on all kinds of difficult road condition and express road
Excellent traction and braking,draining performance
Continuous shoulder designed,excellent anti-irregular-wear performance
High anti-wear formulation ,with low heat built-up,low resistance to rolling
Higher original mileage,suitable for highway road
| SIZE | PR | LOAD INDEX | SPEED SYMBOL | PATTERN DEPTH (mm) | STANDARD RIM | PERMITTED RIM | MAX LOAD （Kg） | PRESSURE (Kpa) | NEW TIRE INFLATED DIMENSION (mm) | ||
| S | D | OD | SW | ||||||||
| ±1.0% | ±3.5% | ||||||||||
| 8.5R17.5 | 12 | 121/120 | L | 13.00 | 6 | 1450 | 1400 | 625/625 | 802 | 215 | |
| 9.5R17.5 | 16 | 129/127 | L | 13.00 | 6.75 | 1850 | 1750 | 750/750 | 842 | 240 | |
| 9R22.5 | 14 | 136/134 | M | 12.00 | 6.75 | 2240 | 2140 | 830/830 | 974 | 229 | |
| 10R22.5 | 16 | 141/139 | M | 12.00 | 7.5 | 2800 | 2650 | 790/790 | 1019 | 254 | |
| 11R22.5 | 16 | 146/143 | M | 15.50 | 8.25 | 7.5 | 3000 | 2725 | 830 | 1054 | 279 |
| 11R24.5 | 16 | 149/146 | M | 14.00 | 8.25 | 3250 | 3000 | 830/830 | 1104 | 279 | |
| 12R22.5 | 18 | 152/148 | M | 15.50 | 9.0 | 8.25 | 3350 | 3075 | 830 | 1085 | 300 |
| 225/75R17.5 | 16 | 129/127 | L | 13.00 | 6.75 | 1850 | 1750 | 725/725 | 784 | 228 | |
| 235/75R17.5 | 16 | 132/130 | M | 13.00 | 6.75 | 2000 | 1900 | 775/775 | 797 | 233 | |
| 245/70R19.5 | 16 | 136/134 | L | 13.00 | 7.5 | 2240 | 2120 | 825/825 | 839 | 248 | |
| 265/70R19.5 | 16 | 140/138 | L | 13.00 | 7.5 | 2500 | 2360 | 775/775 | 867 | 262 | |
| 275/70R22.5 | 16 | 148/145 | L | 15.00 | 8.25 | 3150 | 2900 | 900/900 | 960 | 276 | |
| 275/80R22.5 | 16 | 145/143 | M | 14.00 | 8.25 | 2900 | 2725 | 750/750 | 1012 | 276 | |
| 285/75R24.5 | 16 | 147/144 | M | 14.50 | 8.25 | 3075 | 2800 | 830/830 | 1050 | 283 | |
| 295/75R22.5 | 16 | 146/143 | M | 14.50 | 9 | 3000 | 2725 | 830/830 | 1014 | 298 | |
| 295/80R22.5 | 18 | 152/148 | M | 17.00 | 9 | 8.25 | 3350 | 3075 | 830 | 1044 | 295 |
| 315/70R22.5 | 18 | 154/150 | L | 15.30 | 9 | 3550 | 3150 | 900/900 | 1014 | 312 | |
| 315/80R22.5 | 18 | 154/151 | M | 17.00 | 9 | 9.75 | 4000 | 3650 | 850 | 1076 | 312 |
